Works Bell RAPFIX GTC Steering Wheel Tilt-Up Pop-Up Flip-Up System – Black

Works Bell RAPFIX GTC steering wheel quick release allows for a one-action tilt-up of the steering wheel without sacrificing safety, making it simple to get in and out of a tight seat.

A Works Bell patented ball lock system is used in the RAPFIX GTC system. This technology is based on the one-touch steering system RAPFIX which has a proven track record. The use of a ball to join the convex and concave shapes achieves a smoother bond and less rattle.

A two-step lock is used as a safety measure in emergencies. The lock is not released until the safety trigger is slid in, preventing accidental steering wheel tilt while driving. The plunger mechanism can also suspend (stop) the tilt-up steering wheel in approximately 6 steps. The steering wheel can be suspended at the position desired depending on the meter hood and other characteristic features of the car type. Furthermore, a horn button may also be used. The horn terminals are built-in inside the main body (plug) of the product and in the tilt-up section (socket).

Many competitors’ products with similar functions have structural issues that make controlling the rattling caused by the radial load on the steering wheel difficult. They sacrifice steering and steering feel in exchange for the convenience of tilt-up. RAPFIX GTC has far outperformed conventional products in terms of quality thanks to its patented ball lock system.

Works Bell RAPFIX GTC is a rock-solid piece of kit honed by fine craftsmanship that deserves a spot in the interior of any decent high-performance or track-oriented vehicle.

This is NOT a steering wheel hub, this is an add-on to existing steering wheel hubs. RAPFIX GTC quick release will only bolt to 6×70 mm patterned hubs and 6×70 mm & 6×74 mm bolt pattern steering wheels.

Made in Japan.

Features:

• Tilt-up feature.
• No rattle, no movement, and no flexing when installed.
• Horn terminals are built-in inside the main body (plug) of the product and in the tilt-up section (socket).
• Available in black and silver colours.
• Duraluminium material for higher strength.
• Anodized black finish.
• Meets the safety standards set by ASEA (Auto Sports & Special Equipment Association).

Specifications:

• Height: 57 mm
• Weight: 500 g
• Material: Duralumin
• Surface: Anodized
• Colour: Black
• Hub fitment: 6×70 mm PCD
• Steering wheel fitment: 6×70 mm & 6×74 mm PCD

Patents:

• Japan Patent No. 4689487
• US Patent No. 7441479
